In Stock

Schneider Acti9 Metal Clad P&S Units (IP30) - 3P+E P&S - single door - 3Mod - 30A - (A9HMS330)

3145 - 50% Off ₹ 6289

Inclusive of all taxes

Product will be deliver within 3-4 days.

This Acti9 distribution board comes with single metal door for door opening. This distribution board allows to mount a modular device with a width of 3 modules of 18mm. It provides a 3P+E Electra plug and socket. The In rated current is 30A. The dimensions are (W) 150mm x (H) 305mm x (D) 67mm. The color of the distribution board is white (RAL 9003). The degree of protection is IP30, IK08 with the single metal door. This distribution board is compliant with IS 8623-1, IS 8623-3 and IEC 61439-3 standards.

Color:
  • Brand: SCHNEIDER
  • Category: Switchgears (MCB's, RCCB's, DBs etc)
  • Sub Category: SCHNEIDER
  • Product Code: 368

Main
RangeActi9
Product nameMetal Clad P&S Units
product or component typeConsumer unit
Device applicationPower socket distribution
ColourWhite (RAL 9003)
Provided equipmentElectra plug and socket

Complementary
enclosure mountingSurface
Flush
[In] rated current30 A
poles description3P + E
Total number of 18 mm modules3
Enclosure/cubicle descriptionSingle door enclosure
Enclosure materialGalvanized steel box
Galvanized steel DIN rail
Galvanized steel cable gland plate
CRCA front plate
Height305 mm external:
Width150 mm external:
Depth67 mm external:

Environment
IP degree of protectionIP30
IK degree of protectionIK08
StandardsIS 8623-1
IS 8623-3
IEC 61439-3
Product certificationsCPRI
ERDA
